i-Series - Specs

High Performance Liquid Chromatograph

ENQUIRE NOW

LC-2070 Series
LC-2080 Series

LC-2070 Series

Model		LC-2070 ( UV model without sample cooler )	LC-2070C (UV model)	LC-2070C 3D (PDA model)
P/N		228-65880-58	228-65881-58	228-65882-58
Dimensions		W410 × H605 × D500 mm (Not including reservoir tray height)
Weight		58 kg	63 kg
Available pH range		1 to 13
Pump	Degassing unit	Five Lines: Mobile phase 4 + Rinse solution 1 (Volume 400 mμL)
	Flow rate setting range	0.0001 to 10 mL/min
	Configuration	Four-solvent low-pressure gradient
	Gradient/range of set concentrations	0 to 100%, in 0.1% steps
	Maximum pressure	50 MPa (0.0001 to 3 mL/min) 44 MPa (3.0001 to 5 mL/min) 22 MPa (5.0001 to 10 mL/min)
	System Delay Volume	650 μL (Option: 460 μL, 1100 μL)
Pump	Injection method	Total-volume sample injection
	Injection volume accuracy	±1% (50 L, N = 10)
	Injection volume setting range	0.1 to 100 μL (Option: 0.1 to 50 μL, 1 to 500 μL, 1 to 2,000 μL)
	Injection volume reproducibility	RSD < 0.20% (5.0−2000 L) RSD < 0.25% (2.0−4.9 L) RSD < 0.5% (1.0−1.9 L) RSD < 1.0% (0.5−0.9 L)
	Sample cooler	Not included	4 to 45 °C
Detector		UV	UV	PDA

LC-2080 Series

Model		LC-2080C (UV model)	LC-2080C 3D (PDA model)
P/N		228-65883-58	228-65884-58
Dimensions		W410 × H605 × D500 mm (Not including reservoir tray height)
Weight		63 kg
Available pH range		1 to 13
Pump	Degassing unit	Five Lines: Mobile phase 4 + Rinse solution 1 (Volume 400 mμL)
	Flow rate setting range	0.0001 to 10 mL/min
	Configuration	Four-solvent low-pressure gradient
	Gradient/range of set concentrations	0 to 100%, in 0.1% steps
	Maximum pressure	70 MPa (0.0001 to 3 mL/min) 44 MPa (3.0001 to 5 mL/min) 22 MPa (5.0001 to 10 mL/min)
	System Delay Volume	460 μL (Option: 650 μL, 1100 μL)
Pump	Injection method	Total-volume sample injection
	Injection volume accuracy	±1% (50 L, N = 10)
	Injection volume setting range	0.1 to 50 μL (Option: 0.1 to 100 μL, 1 to 500 μL, 1 to 2,000 μL)
	Injection volume reproducibility	RSD < 0.20% (5.0−2000 L) RSD < 0.25% (2.0−4.9 L) RSD < 0.5% (1.0−1.9 L) RSD < 1.0% (0.5−0.9 L)
	Sample cooler	4 to 45 °C
Detector		UV	PDA

LC-2050C (UV model)

Pump

Degassing unit	Five Lines: Mobile phase 4 + Rinse solution 1 [Volume 400 μL]
Pumping method	Parallel-type double plunger
Pulsation	≤ 0.1 MPa [1.0 mL/min,10 MPa, Water]
Flow rate setting range	0.0001 to 10 mL/min
Flow rate accuracy	≤ ±1% or ≤ ±2 μL/min, below whichever is greater [0.01 to 2 mL/min, Specified condition] ≤ ±2% [2 to 5 mL/min, Specified condition]
Flow rate precision	< 0.06 %RSD or < 0.02 minSD, below whichever is greater
Configuration	Four-solvent low-pressure gradient
Gradient / range of set concentrations	0 to 100%, in 0.1% steps
Gradient / concentration accuracy	±0.5% [0.1 to 2 mL/min, 1 to 20 MPa, Specified condition]
Gradient / concentration precision	±0.1% [1 mL/min,10 MPa, Specified condition]
Maximum pressure	50 MPa [0.0001 to 3 mL/min] 44 MPa [3.0001 to 5 mL/min] 22 MPa [5.0001 to 10 mL/min]
System Delay Volume	650 μL [Option: 460 μL, 1100 μL]

Show Less

Autosampler

Sample injection method	Total-volume sample injection
Injection volume accuracy	±1% [50 μL, N = 10]
Injection volume setting range	0.1 to 100 μL [Option: 0.1 to 50 μL, 1 to 500 μL, 1 to 2,000 μL]
Injection volume reproducibility	RSD < 0.20% [5.0−2000 μL] RSD < 0.25% [2.0−4.9 μL] RSD < 0.5% [1.0−1.9 μL] RSD < 1.0% [0.5−0.9 μL]
Cross-contamination	0.0025% [Caffeine, Specified condition]
Injection cycle time	Min. 14 sec [Specified condition]
Samples for processing	336 [1 mL], 216 [1.5 mL], 112 [4 mL], 4 [MTP/DWP]
Sample cooler	4 to 45°C [Room temperature needs to be 30°C or lower and the humidity 70% or less to go down to 4°C. Room temperature needs to be 15°C or higher to go up to 45°C.]
Injection linearity	> 0.9999 [1 to 100 μL, Specified condition]

Show Less

Column Oven

Heating and cooling method	Forced air circulation method
Containable column size	Six columns 10 cm long Three columns 30 cm long One 30 cm long column if a CTO unit (optional) for i-Series low-temperature analysis is installed. (Two columns up to 15 cm long or one column 30 cm long if an FCV tubing kit for i-Series low-temperature analysis is also installed.)
Temperature control range	Room temperature −12 °C (−15 °C if an optional unit is installed) to 90 °C
Temperature control precision	±0.1°C
Temperature accuracy	±0.8°C (Specified condition)
Flow rate switching valve	Max. 1 pc

Show Less

UV Detector

Wavelength range	190 to 700 nm
Spectral bandwidth	8 nm
Wavelength accuracy	≤ ±1 nm
Wavelength Reproducibility	≤ ±0.1 nm
Noise	≤ ±2.5 × 10−6 AU, (250 nm, Specified condition)
Drift	≤ 100 × 10−6 AU/h [250 nm, Specified condition]
Simultaneous monitoring of 2 wavelengths	Enable [Any 2 wavelengths of 190 to 370 nm or 371 to 700 nm]
Linearity	Up to 2.5 AU (5%)
Sampling rate	Up to 100 Hz
Light source	Deuterium (D2) lamp
Flow Cell	12 μL (10 mm, TC), 12 MPa
Option cell	High-Speed: 8 μL [10 mm, TC] Semi-micro: 2.5 μL [5mm, TC]

Show Less

Miscellaneous

Dimensions	W410×H605×D500 mm [Not including reservoir tray height]
Weight	63 kg
Available pH range	1 to 13
Materials for parts in contact with liquids	Stainless steel (SUS316L, SUS316), FEP, PEEK, PTFE, perfluoroelastomer, ruby, sapphire, Hastelloy® C, GFP, ceramic, PFA, quartz, PPS

Show Less
